Eurosafe Italia specialises in the production and sale of smoke barriers, fire curtains and industrial fire protection systems. Contact the Bologna office for info and inspections.

Contact

Design and production of fire curtains

Specialising in the manufacture of smoke barriers and fire curtains, Eurosafe Italia provides state-of-the-art solutions that can be customised to suit different application and usage needs. Fire curtains, in particular, represent a passive system that allows small and large compartments to be created in order to keep in line with EU directives regarding fire loads in buildings.

Fire curtains can be applied in any context and their installation simply requires attachment to walls, floors and fire-resistant surfaces, with the exception of escape routes, for which, being an automatic device, they are prohibited by law.

The fire barriers are also equipped with a Fail Safe Gravity system, which is designed to ensure proper operation in the presence of an alarm or in the event of an electrical failure, due to damage to the control unit or the loss of mains power for more than 6 hours.

  • protective curtains

    Slide title

    Write your caption here
    Button
  • fire protection

    Slide title

    Write your caption here
    Button

Operation

Smoke barriers and fire curtains are housed inside a galvanised steel collection box. As soon as the event occurs, they descend at a controlled speed into side guides, which prevent the flames and smoke from escaping.

The system is also equipped with a control unit, which acts as an intermediary between the curtain and the fire detection system in the building. If no fire detection system is present in the company, the fire curtain is supplied by Eurosafe Italia complete with ORS smoke detectors.

Control unit

A control unit that sends an activation signal to the motor in the event of fire, a signal by which the blind proceeds to descend.

The flexibility of the system allows for field programming of the control parameters and coordination of the tubular operators of the smoke and heat barriers.

Features:
Protection index > IP55
Power supply > 100-240 VAC 50-60 Hz
Output > 24 VDC
Battery > 2 x NP 12V

Reference standards

  • UNI EN 13501-2:2016

    Fire classification of construction products and building elements - Part 2: Classification using results of fire resistance tests, excluding ventilation systems.


  • UNI EN 16034:2014

    Pedestrian, industrial, commercial and garage doors and opening windows - Product standard, performance characteristics - Fire resistance and/or smoke control characteristics.

  • UNI EN 1634-1:2014+A1:2018

    Fire resistance and smoke control tests for door and shutter assemblies, openable windows and elements of building hardware - Part 1: Fire resistance test for door and shutter assemblies and openable windows.

  • UNI EN 1363-1:2012

    Fire resistance testing - Part 1: General requirements.


  • UNI EN 15269-11:2018

    Extended application of fire resistance and/or smoke dispersion test results for doors, locks and opening windows and their components - Part 11: Fire resistance of operable fabric curtains.

Contact our offices for estimates on the installation of smoke barriers and fire curtains
